Boost Charge Function 12v 24v 600w Wind Solar Charge Controller with Overload Protection

DESCRIPTIONS:

MPPT Wind solar hybrid street-lighting controller is the firstly apply MPPT technology for the small power wind generator in china. With the application of this technology, the charge efficiency has vastly improved under the situation of low-wind, and obvious exceed the traditional PWM charging mode of 30%. Presently, we have solved such so technical problem on charging efficiency of the low-power wind generator already. Especially apply to the horizontal and vertical low-power wind generator of 100W to 600W. This type controller has strong compatibility and a great various protection functions, have more 10 years of application practice to improve performance continuously to make it has high reliable and stability. It can be used to the street lighting, monitoring system, outdoor advertisement, home type generation system etc.

Wind generator control set-up definition
Rated Wind Turbine Power (12V/24V)	100W-300W / 200W-600W (compatible)
Wind Turbine brake voltage (12V/24V)	15Vac / 30Vac
Wind Turbine brake current	23A
Solar panel set-up definition
PV max power (12v/24v)	150W / 300W
PV max charge current	12.5A
Warranty	Wind turbine:5 years; Solar panel 10 years; Battery:3 Years; Other parts: 13 Months
Battery management definition
Over-discharge Voltage (12v/24v)	10.5V /20.0V
(Over-discharge Recovery Voltage (12v/24v)	12.0V / 24.0V
Over-charge Voltage (12v/24v)	15.0V / 30.0V
Over-charge Recovery Voltage (12v/24v)	13.5V / 27.0V
Data-transfer port	RS232/485/wifi/GPRS
Dimension(W*L*H) [mm]	146X152X78
Net-weight[kg]	1.2

Package details

Q1:Are you a factory or trade company?

We are a factory who has more than 10 years experience in manufacturing; strong aftersale service team and technical support. Free design according to client requirements.

Q2:Whats the MOQ? We have stock and semi-finished products with enough base materials for new sampleand order for all models, So small quantity order is accepted, it can meet your require.ment very well.

Q3:Why others price much cheaper? We try our best to ensure our quality to be the best one in the same level price products. We believe safety and effectiveness are the most important.

Q4:Can I have a sample for testing?

Yes, you are welcome to test samples before quantity order; Sample order will be sentout 2-3 days generally.

Q5:Can Iadd my logo on the products?

Yes,OEM and ODM are available for us. But you should send us the Trademark authori-zation letter.

Q6 :Do you have inspection procedures?

100% self-inspection before packing.

We located in APEC High-Tech Industrial Park, Hefei National Hi-Tech Industrial Development Zone, is a professional and high-tech enterprise that engaged in wind generation, photovoltaic system and other renewable energy R&D, manufacturing and marketing.
Sunway power main products are PV solar system, portable solar system, Solar panels, MPPT solar and wind controller series, PV and wind system controller series, solar inverter. Our products had many intellectual property, and gained 12 national patents, software copyright certificate, passed the testing from national testing organization and CE Certification Institution. Also we have registered brand successfully. Our company has been rated Hi-tech Enterprise and gained ISO-9001certificate since August, 2011 year.
