OEM/ODM Acceptable 12V Sealed Gel Battery for Solar Energy System 150ah 200ah 250ah

Ask Lasest Price
Brand Name :	SUNEVER
Model Number :	CNJ-100/250AH
Certification :	CE, ce
Supply Ability :	1200 Piece/Pieces per Month
Price :	$75.00 - $208.00/pieces

Add to Cart

Product Details
Company Profile

OEM/ODM Acceptable 12V Sealed Gel Battery for Solar Energy System 150ah 200ah 250ah

Product Description of Gel battery

CNJ series GEL battery utilizes AGM and gel mixed technology, componsed of strong grids, high purity lead and fumed silica Gel electrolyte with good cycle life and wide temperature range performance. The unique plate design of the SUNWAY CNJ series gel battery provides excellent frequent cyclic discharge performance. Patented structure design and focused on energy storage batteries with 30 years' experience, CNJ series achieve a cost effective product and widely used in different solar and wind system, lighting system, marine & RV energy storage parts.

Key Features : of Gel battery

♦Gelled electrolyte made by mixing sulfuric acid with silica fume
♦The electrolyte is gel like ,immobile and does not leak ,enabling uniform reaction of each part of the plate .
♦High rate discharge performance due to tight assembly technology
♦Strong heat dissipation and wide operating temperature range
♦Avoid acid mist being separated out , environment friendliness
♦Efficient venting system release excessive gas automatically

Technology data

Rated

voltage

Capacity

（10hr,1.80V/Cell）

Weight

Max

discharge current

Max

charging current

Self-discharge

（25℃）

Using

temperature

Cover Material

12V

100AH

30.0kG

30I10A(3min)

≤0.25C10

≤3%/month

15℃~25℃

ABS

12V

150AH

40.0KG

30I10A(3min)

≤0.25C10

≤3%/month

15℃~25℃

ABS

12V

200AH

55.5KG

12V

250AH

63.0KG

Using temperature

Charging Voltage （25℃）

Charging Voltage
（25℃）

Charging Mode（25℃）

Cycle life

Capacity
Affffected by
Temperature

Discharge：-45℃~50℃

floating charge：

Float Charge: 2.275±0.025V/Cell

100%DOD 490 times

105% @ 40℃

Charge：-20℃~45℃

13.5V-13.8V

Temperature parameters：±3mV/Cell ℃

50%DOD 1250 times

80% @ 0℃

Storage：-30℃~40℃

equalizing charge：

14.1V-14.4V

Cycle Charge： 2.45±0.05V/Cell

30%DOD 2150 times

58% @ -20℃

Temperature Compensation Coeffiffifficient
±5mV/Cell ℃

Ø Q1. Can your battery be delivered by sea and air?
A: Yes, our batteries can be delivered both by sea and by air. We have MSDS, test report for safe transport as non-dangerous products.

Ø Q2. Can I put my logo on the battery?
A: Yes, you can print your logo on our batteries Freely.Welcome to share us your logo design.

Ø Q3. Can I fast charge my battery?
A: Fast charging is not recommended as ifs harmful for the battery.

ØQ4. Can I do a partial replacement of my batteries?
A: Partial battery replacement of lead acid battery banks is not recommended.

Ø Q5. How about your delivery time usually?
A: About 7 days for stock products, around 20 days for half container products, 30 days for 20ft full container products.

Ø Q6. Why battery has different capacity at different hour rate?

A: The capacity of a battery, in Ahs, is a dynamic number that is dependent on the discharge current. For example, a battery that is discharged at 10A will give you more capacity than a battery that is discharged at 100A. With the 20-hr rate, the battery is able to deliver more Ahs than with the 2-hr rate because the 20-hr rate uses a lower discharge current than the 2-hr rate.
